MDDHT3530E02 AC SERVO DRIVER

HCFA SV-X3EB040A-A2 AC Servo Drive

• AC Servo Drive 400W 220VAC Single Phase
• EtherCAT / CANopen / Pulse Analog model options
• Autotuning and fast commissioning from HCS-Studio interface via USB port
• 6 control modes: Position control / Speed control / Torque control / Position-Speed Control / Position-Torque control / Speed-Torque control
• Easily monitor and adjust all parameters via digital keypad
• Torque limiting with digital inputs of the drive and parameters
• Switching between modes during operation with dual mode feature
• Internal positioning with 9 digital inputs, 9 digital outputs, 2 Analog inputs
• Built-in home function
• 500Khz high resolution position control with Pulse Train
• Increased engine speed up to 6000rpm
• Low inertia / Medium inertia / High inertia / Ultra high inertia engine options
• Motor, battery and battery box with optional Absolute Encoder to keep the position in memory in case of power outage
• Master Slave operation feature with encoder signal output
• Internal Positioning
• More precise and smoother movements can be achieved with the Notch filter feature.
• Provides precise vibration-free operation with automatic resonance suppression filter
• 3-5-10 meter ready-made cable options
• Precise position control thanks to 17 bit absolute encoder
• Monitoring and resetting all warnings and errors via EtherCAT
• Full compatibility with the Packaging industry thanks to TouchProbe and Latch inputs
• Condition: Used
